Argus — AI Video Analytics Platform

Multi-camera AI surveillance with YOLOv8, Re-ID tracking, LPR, face recognition, zone alerting, and a benchmarked swarm agent architecture.

---

Quickstart | Project Status | Features | Security | Swarm Architecture | Data Pipeline | API Reference | Observability | Testing | Troubleshooting

---

📖 Overview

Argus is an AI-powered video analytics platform for real-time CCTV monitoring. It ingests concurrent RTSP, video-file, or webcam streams, runs YOLOv8 object detection on each frame, assigns persistent tracking IDs via a Kalman-filtered tracker, and evaluates zone-based rules (intrusion, loitering) to generate actionable security events.

The system employs a decentralised multi-agent swarm where autonomous agents (YOLO, Face, LPR) bid for compute resources through a Consortium Broker. The swarm is benchmarked against a linear baseline rather than assumed better — see Swarm Architecture for the measured numbers, and set ARGUS_NO_SWARM=1 to run the linear path.

Metaphor: In Greek mythology, Argus Panoptes was a hundred-eyed giant who served as a watchful guardian. This platform embodies that vigilance.

📖 File-by-file breakdown: FOLDER_STRUCTURE.md · Production gap analysis: PRODUCTION_ROADMAP.md

---

📍 Project Status

Current Development Status: Beta / Hardened Edge Prototype

Architecture Component	Status	Implementation Details & Evidence
Detection & Tracking Pipeline	✅ Working	YOLOv8n + DeepTracker (Kalman filter + Hungarian matching). CPU baseline: ~1.3–1.6 FPS/cam; GPU: ~30 FPS/cam.
Authentication & RBAC	✅ Enforced	JWT + 3-role RBAC (admin, operator, viewer). Sliding-window rate limiter protects auth routes against brute-force.
Face Recognition & Biometrics	🔒 Opt-in	Disabled by default. When enabled, embeddings are AES-256-GCM encrypted; new enrollments do not save source face crops. Older plaintext image files require explicit cleanup.
Cryptographic Audit Trail	✅ Tamper-Evident	Append-only SHA-256 hash chaining with integrity verification (GET /api/v1/audit/integrity).
Database Architecture	✅ Dual-Tier	SQLite (default zero-install edge) + PostgreSQL adapter (backend/database/postgres.py) with migration tooling.
CI & Security Workflows	⚙️ Configured	GitHub Actions cover Python 3.11/3.13, frontend builds, security scans, and Docker image checks; badges above link to the latest workflow runs, when available.
Scientific Evaluation Set	⚠️ Not published	The evaluation harness exists, but this repository does not include a public labeled ground-truth dataset yet.
Swarm Agent Benchmark	📊 One recorded run	On a bundled 40-frame CPU sample: 1.27 FPS linear vs 1.61 FPS swarm, with the same detection count; no ground-truth accuracy comparison or hardware metadata.
TLS / Production Exposure	⚠️ Reverse Proxy Required	Cleartext HTTP is development-only. Production requires fronting with Caddy/Nginx (recipes in infrastructure/).

📖 Security Policy: SECURITY.md · Database Migration: docs/DATABASE_MIGRATION.md · Roadmap: PRODUCTION_ROADMAP.md

---

🚀 Quick Start

One command, any OS

python argus.py start

That is the whole install. It works the same on Windows, macOS and Linux, and it is safe to re-run — everything below is skipped once it is already done:

1. generates a strong ARGUS_JWT_SECRET into .env (first run only)
2. picks a runtime — Docker if the daemon is responding, otherwise a local .venv (force either with --native / --docker)
3. installs dependencies, using CPU PyTorch wheels so the download is ~200 MB instead of ~2.5 GB of unusable CUDA payload
4. creates the database and seeds the admin user
5. builds the dashboard and serves it from the API on one port
6. waits for /api/v1/health, then opens your browser

  Argus is running
    Dashboard   http://localhost:8000
    API docs    http://localhost:8000/docs
    Login       admin (set with: python argus.py create-admin)

    Stop it     python argus.py stop

Prefer not to use a terminal? Double-click start.bat (Windows) or start.command (macOS/Linux). stop.bat / stop.command shut it down.

Prefer make? make start and make stop wrap the same launcher, and make docker-start / make docker-stop run it in a container (generating the required signing key on first use). make on its own lists every target. The Makefile is a thin wrapper, never a second implementation — Windows has no make, so the logic stays in argus.py.

Command	What it does
python argus.py start	Set everything up and run it
python argus.py stop	Stop everything (graceful, then forced)
python argus.py status	Show mode, port, PID and health
python argus.py create-admin	Create or update admin credentials (interactive prompt)
python argus.py doctor	Check this machine before installing
python argus.py reset	Delete the venv/build (--all also drops the DB)

Useful flags: --port 9000, --native, --docker, --rebuild, --reinstall, --no-browser, --host 127.0.0.1.

If something goes wrong, start prints the tail of .argus/backend.log and tells you where the full log is. Run python argus.py doctor first if you want to check Python, Node, Docker, disk space and port availability up front.

The launcher itself imports only the Python standard library — it has to run before any dependency exists. A test enforces that.

---

Manual setup (for development)

Prefer hot-reload and separate processes? The original flow still works.

Prerequisites

• Python 3.9+ and Node.js 18+
• 4 GB RAM minimum
• RTSP camera streams or a local webcam for testing

1. Backend

python -m venv venv
# Windows: venv\Scripts\activate
# Linux/Mac: source venv/bin/activate

pip install -r requirements.txt

# Required: a signing key of at least 32 characters.
# Without it the server generates an ephemeral key, so every restart
# invalidates all issued tokens (fine for a demo, useless in production).
export ARGUS_JWT_SECRET="$(python -c 'import secrets;print(secrets.token_urlsafe(48))')"

python -m uvicorn backend.api.main:app --reload --host 127.0.0.1 --port 8000

2. Create a login

Argus authenticates against the Django auth_user table — there is no second user store to drift out of sync. Create the first superuser:

# Create the Django auth tables and initialize a secure superuser:
python backend/scripts/run_admin.py --setup-only

# Set a password interactively before first login
python argus.py create-admin --username admin

Roles are derived from Django group membership: a user in the operator group gets the operator role, viewer gets viewer, and any superuser or staff account is an admin. A user in no group defaults to viewer (least privilege).

3. Frontend

cd frontend
npm install
npm run dev            # Serves on http://localhost:3000

The dashboard opens on a login screen. Tokens are held in sessionStorage and refreshed transparently, so a 30-minute access-token expiry will not sign an operator out mid-shift.

💡 Shortcut: python argus.py start does all of the above in one step and serves the built dashboard on port 8000 instead.

4. Access

Service	URL
Dashboard (argus.py start)	http://localhost:8000
Dashboard (npm run dev)	http://localhost:3000
├ Cameras / Events / Analytics	/ · /events · /analytics
└ Adaptive Learning	/learning
API banner (JSON)	http://localhost:8000/api
API Docs	http://localhost:8000/docs
Prometheus metrics	http://localhost:8000/metrics
WebSocket Stream	ws://localhost:8000/api/ws/stream/{camera_id}?token=<jwt>
Django Admin	http://localhost:8001/admin

5. What a fresh clone does not include

data/ and the model weights are gitignored, so after cloning you will need:

Missing	How to get it
backend/models/yolov8n.pt	Downloaded automatically on first run by ultralytics, or fetch it manually
data/argus.db	Created automatically at startup; add users via Django admin (step 2)
data/demo_clip.mp4	Included — it is the one exception, because the test suite needs it

Regenerate the demo clip if you ever need to:

python backend/scripts/make_demo_clip.py --source path/to/street_photo.jpg

It reports how many objects YOLO finds in the first frame. Use a real photograph — the detector returns nothing on drawn shapes, so a synthetic clip looks identical to a broken pipeline.

6. Try it without a camera

No RTSP stream handy? Point a camera row at a local video file — the ingestion layer detects file sources, paces them to their native FPS, and loops on EOF:

curl -X POST http://localhost:8000/api/v1/cameras \
  -H "Authorization: Bearer $TOKEN" -H 'Content-Type: application/json' \
  -d '{"name":"Demo","rtsp_url":"data/demo_clip.mp4","location":"Test"}'

---

🌟 Features

Core Capabilities

• Multi-Camera Ingestion – Concurrent RTSP / video-file / webcam streams with auto-reconnect, exponential backoff, native-FPS pacing for files, and EOF looping.
• YOLOv8 Detection – Person, vehicle, bicycle, and object detection with configurable confidence / IoU thresholds. Ships with yolov8n.pt.
• Object Tracking – Kalman-filtered motion prediction with two-stage association (IoU, then size-scaled centre distance) so identity survives the ~1s gap between processed frames on CPU.
• Zone-Based Rules – Polygon virtual zones (intrusion, loitering) and line tripwires (line_crossing), keyed on persistent track IDs. Scene-scoped rules (speed_violation, fall_detection, abandoned_object) need no zone and run on every camera.
• Rule Honesty – GET /api/v1/rules/status reports, per rule, whether it is configured, implemented, and actually able to fire here. A rule whose prerequisite is missing (no ground-plane calibration, no pose keypoints) reports its blocker instead of quietly producing nothing — or worse, producing a fabricated number.
• Observations Become Events – Perception findings (dwell, pacing, abandonment, occupancy anomalies, disappearances, scene changes) are promoted into the operator event feed with the evidence that justified them. Only grounded, actionable observations are promoted; bookkeeping kinds stay out.
• Event Management – SQLite-backed event store with sliding-window deduplication (one event per subject per episode, not one per window), snapshot capture, and MQTT publishing. Events follow an enforced lifecycle — detected → open → acknowledged → resolved, or false_positive — recording who acted and when; an illegal transition is rejected, not silently written.
• Real-Time WebSocket Streaming – Interleaved binary (JPEG) + JSON (detection metadata), authenticated at the handshake.
• Data Retention – Scheduled purge of events, snapshots, anomalies, plates, and audit rows on independent per-type schedules.
• Image Enhancement – CLAHE, denoising, sharpening, night vision, deblur, and HDR auto-enhancement.
• Cross-Camera Re-ID – Person re-identification across non-overlapping cameras using feature embeddings and cosine similarity.

Degrades gracefully when optional models are absent — the system logs the fallback at startup rather than failing:

Feature	With optional dependency	Without it
License Plate Recognition	PaddleOCR text recognition	Basic OCR heuristics
Face Recognition	opencv-contrib LBPH matching	Haar-cascade detection + histogram matching
Pose Estimation	MediaPipe 33-keypoint skeletons	Geometric fallback pose estimation

---

🔐 Authentication & RBAC

Every API route requires a bearer token except four intentional exceptions: GET /api/v1/health, GET /, POST /api/v1/auth/login, and POST /api/v1/auth/refresh.

Roles

Role	Can do
viewer	Read cameras, zones, events, analysis, anomalies, trackers, poses, metrics; watch live streams
operator	Everything a viewer can, plus create/update/delete zones, run cross-camera tracking, control the webcam, submit video for processing
admin	Everything, plus camera CRUD, the face database (register/list/delete), and the audit log

Roles come from Django group membership and are re-read from the database on every request. A token whose role claim has been tampered with is therefore harmless — the claim is never trusted, only the user ID is.

Auth endpoints

Method	Path	Description
POST	/api/v1/auth/login	Exchange username/password for an access + refresh token pair
POST	/api/v1/auth/refresh	Exchange a refresh token for a new access token
GET	/api/v1/auth/me	Current user identity and role
GET	/api/v1/audit	Query the audit trail (admin only)

TOKEN=$(curl -s -X POST http://localhost:8000/api/v1/auth/login \
  -H 'Content-Type: application/json' \
  -d '{"username":"admin","password":"changeme"}' | python -c "import sys,json;print(json.load(sys.stdin)['access_token'])")

curl http://localhost:8000/api/v1/cameras -H "Authorization: Bearer $TOKEN"

Hardening that is actually in place

• Brute-force lockout — 5 failed attempts locks an account for 300 s; the correct password is refused while locked (otherwise the lockout is decorative).
• Token separation — a refresh token is rejected where an access token is required, so a long-lived credential cannot be replayed as a short-lived one.
• WebSocket auth before accept() — unauthenticated upgrades are refused at the handshake with a 403 rather than accepted and then closed.
• Static mounts gated — /snapshots is only mounted when auth is disabled, because a StaticFiles mount bypasses route dependencies entirely.
• Audit trail — every mutation and auth attempt is recorded with actor, role, client IP, and outcome (including denied). Writes never raise; a failed audit write must not take down the request path.
• No plaintext secrets in config — config.yaml supports ${VAR} interpolation and startup refuses to run with unresolved secret placeholders.

Environment variables

Variable	Default	Purpose
ARGUS_JWT_SECRET	(ephemeral)	HS256 signing key, min 32 chars. Set this.
ARGUS_ACCESS_TOKEN_MINUTES	30	Access token lifetime
ARGUS_REFRESH_TOKEN_DAYS	7	Refresh token lifetime
ARGUS_LOGIN_MAX_ATTEMPTS	5	Failures before lockout
ARGUS_LOGIN_LOCKOUT_SECONDS	300	Lockout duration
ARGUS_DISABLE_AUTH	unset	Disables auth entirely — local development only
ARGUS_CORS_ORIGINS	localhost:3000/5173	Comma-separated allowlist
ARGUS_NO_SWARM	unset	1 forces the linear pipeline
ARGUS_LOG_FORMAT	text	json for structured log ingestion
ARGUS_LOG_LEVEL	INFO	Root log level

---

🤖 Swarm Agent Architecture

Agent	Role	Local Evolution
YOLO Detection Agent	Primary object detection	Optimises yolo_conf_threshold, iou_threshold, input_resolution_scale, tracker_matching_threshold via a genetic algorithm.
Face Recognition Agent	Face matching when persons detected	Evolves match_distance_threshold, min_face_size_px, track_timeout, frame_skip_cadence.
LPR Agent	License plate OCR when vehicles detected	Evolves segmentation_threshold, min_plate_height_px, resolution_downscale, detection_confidence, ocr_beam_width.
Consortium Broker	Resource auctioneer	Collects agent bids → resolves allocations → posts context to shared blackboard.
Logic Mutator	AST-constrained rule generation	Generates and evaluates internal Python filter rules with AST checks and restricted globals. This is not a sandbox for hostile code.
Evolutionary Engine	Cross-agent optimiser	Runs a self-contained genetic algorithm (elitism, crossover, Gaussian mutation) over the pipeline parameter space. No external GA library is used.

What one recorded swarm run measured

40 frames of a 640×480 clip, CPU inference, each variant in a separate process so module-level singletons cannot leak state between runs:

Mode	FPS	p50 latency	p95 latency	Detections/frame	Zero-detection frames
Linear baseline	1.27	784.20 ms	840.84 ms	12.8	0
Swarm	1.61	612.78 ms	750.53 ms	12.8	0

In this recorded run only: the swarm processed 1.61 vs 1.27 FPS (+26.8%) and p50 latency was 612.78 vs 784.20 ms (−21.9%). Both modes returned the same mean count (12.8 detections/frame), but this benchmark has no ground-truth labels, so it does not establish equal detection accuracy. Hardware metadata was not captured; treat these figures as one sample, not a general performance claim.

Reproduce it yourself:

python tests/swarm_benchmark.py --frames 40 --json docs/swarm_benchmark_results.json

⚠️ The first honest run of this benchmark reported +45.2% FPS and −35.5% detections. The "speedup" was the broker starving the detector until it replayed a stale result forever. A performance number without a quality number next to it is not a result — see PRODUCTION_ROADMAP.md §5 for the full post-mortem.

Infrastructure

• Docker Compose – Backend, frontend, Mosquitto MQTT, Qdrant vector DB, Kafka, Elasticsearch + Grafana.
• MediaMTX – Optional RTSP/HLS/WebRTC rebroadcast server.
• MQTT – Event publishing to argus/events/{camera_id}/{rule_type}.
• SQLite – Local persistent storage for cameras, zones, events, and behaviour profiles.
• Qdrant / Kafka – Optional vector storage and event streaming for external analytics.

---

🔄 Data Pipeline

┌──────────────┐     ┌─────────────────┐     ┌──────────────────────────────┐
│  RTSP Camera │───▶│ stream_ingestion │───▶│   ProcessingCoordinator      │
│  / Webcam    │     │ (cv2.VideoCapture│    │  (swarm OR fallback loop)    │
└──────────────┘     │  + frame queue)  │    │                              │
                     └─────────────────┘     │  ┌────────────────────────┐  │
                                             │  │  YOLO Agent (primary)  │  │
                                             │  │  → detections [dict]   │  │
                                             │  └───────────┬────────────┘  │
                                             │              ▼               │
                                             │  ┌────────────────────────┐  │
                                             │  │  DeepTracker           │  │
                                             │  │  → Kalman filter       │  │
                                             │  │  → persistent track IDs│  │
                                             │  └───────────┬────────────┘  │
                                             │              ▼               │
                                             │  ┌────────────────────────┐  │
                                             │  │  LogicMutator          │  │
                                             │  │  →AST-constrained rule filter│  │
                                             │  └───────────┬────────────┘  │
                                             │              ▼               │
                                             │  ┌────────────────────────┐  │
                                             │  │  Consortium Broker     │  │
                                             │  │  → post context        │  │
                                             │  │  → resolve agent bids  │  │
                                             │  └───────────┬────────────┘  │
                                             │              ▼               │
                                             │  ┌────────────────────────┐  │
                                             │  │  Face Agent (cond.)    │  │
                                             │  │  LPR Agent (cond.)     │  │
                                             │  └───────────┬────────────┘  │
                                             │              ▼               │
                                             │  ┌────────────────────────┐  │
                                             │  │  PoseEstimator         │  │
                                             │  │  AnomalyDetector       │  │
                                             │  │  SpeedHeightAnalyzer   │  │
                                             │  └───────────┬────────────┘  │
                                             │              ▼               │
                                             │  ┌────────────────────────┐  │
                                             │  │  RulesEngine           │  │
                                             │  │  → zone checks         │  │
                                             │  │  → event generation    │  │
                                             │  └───────────┬────────────┘  │
                                             └──────────────┼───────────────┘
                                                            ▼
                           ┌─────────────────────────────────────────────┐
                           │         camera_analysis cache               │
                           │  (detections, face, lpr, pose, anomalies)   │
                           └──────────┬──────────────────────┬───────────┘
                                      ▼                      ▼
                           ┌──────────────────┐   ┌──────────────────────┐
                           │  EventStore (DB) │   │  WebSocket Stream    │
                           │  + MQTTPublisher │   │  (JPEG binary + JSON)│
                           └──────────────────┘   └──────────┬───────────┘
                                                             ▼
                                                  ┌──────────────────────┐
                                                  │  LiveVideoPlayer.jsx │
                                                  │  → canvas overlays   │
                                                  │  → bboxes + labels   │
                                                  │  → zone polygons     │
                                                  └──────────────────────┘

WebSocket Protocol (ws://localhost:8000/api/ws/stream/{camera_id}?token=<jwt>)

The connection is authenticated before the upgrade is accepted; an unauthenticated handshake is refused with HTTP 403. Two message types are interleaved:

1. Binary message – JPEG-encoded video frame
2. Text message – JSON detection metadata:

{
  "camera_id": 2,
  "detections": [
    {
      "track_id": 1,
      "class": "person",
      "confidence": 0.8251198530197144,
      "bbox": { "x1": 495, "y1": 237, "x2": 590, "y2": 442 }
    }
  ],
  "timestamp": "2026-08-17T16:59:47.691052Z",
  "timestamp_unix": 1786985987.6910653
}

Field notes: the class label key is class (not class_name), bbox is an object with x1/y1/x2/y2 (the frontend also accepts a 4-element array), and timestamp is ISO 8601 UTC with timestamp_unix alongside for arithmetic.

---

🖥️ Operator dashboard

The default screen is a command center: a live video wall with detection overlays, an alert feed, and — deliberately — the state of the things that silently fail.

• Video wall. Frames arrive over the documented WebSocket protocol and detections are drawn client-side as corner brackets with track ID and confidence. Brackets occlude far less of a subject than full rectangles, which matters when the operator is trying to identify the person inside the box. Overlay geometry accounts for letterboxing: the frame is rendered with object-fit: contain, so scaling by the element size would smear every box across the black bars.
• Liveness is measured, not assumed. A stalled camera holds its socket open indefinitely, so an open connection proves nothing. Each tile runs its own frame clock and degrades LIVE → STALE → NO SIGNAL, rather than showing an old picture labelled live.
• Failure never renders as zero. When a poll fails the panel keeps its last known value and marks itself stale. A surveillance dashboard that prints "0 events" after a failed request is actively dangerous — the operator reads it as "nothing happened".
• Delivery state is on screen. If no alert channel can deliver, a banner says so. Argus spent its whole history recording events and sending them nowhere; that failure mode is now impossible to miss.
• Evidence is fetched with credentials. Snapshots and clips are role-protected, and neither <img src> nor <video src> can carry a bearer token, so both are fetched through the authenticated client and played from object URLs.

Run it with python argus.py start (builds the UI and serves it from the API on port 8000), or npm run dev in frontend/ for hot reload on port 3000.

---

📊 API Reference

98 registered routes: 92 under /api/v1; the rest are system, streaming, WebSocket, and documentation endpoints. GET / is excluded: it serves the dashboard when frontend/dist exists and a build hint when it does not, so it is not part of the API surface.

Of the 92 /api/v1 operations, 89 require a token and 3 are public. Everything requires Authorization: Bearer <token> except the entries marked public below.

The Role column is the minimum role required.

Interactive docs: http://localhost:8000/docs

CityOS Intersection Intelligence

Geometry-only traffic layer (no biometrics enter it): digital twin, road-user classification and trajectories, wrong-way / near-miss / VRU safety analytics, traffic-flow statistics and signal-optimiser control.

Method	Path	Role	Description
GET	/api/v1/cityos/status	viewer	Intersections overview + privacy posture
GET	/api/v1/cityos/twin	viewer	Digital-twin snapshots for all intersections
GET	/api/v1/cityos/twin/{camera_id}	viewer	Digital twin for one camera's intersection
GET	/api/v1/cityos/alerts	viewer	Merged safety alert feed (kind filter)
GET	/api/v1/cityos/flow/{camera_id}	viewer	Volume series, turning matrix, speed summary
GET	/api/v1/cityos/signal/{camera_id}	viewer	Signal phase state + adaptive recommendation
POST	/api/v1/cityos/signal/{camera_id}/mode	operator	Set mode: fixed / adaptive / manual
POST	/api/v1/cityos/signal/{camera_id}/phase	operator	Manual override: force NS or EW green
POST	/api/v1/cityos/bind	admin	Bind a camera to a named intersection

Authentication

Method	Path	Role	Description
POST	/api/v1/auth/login	public	Username/password → access + refresh tokens
POST	/api/v1/auth/refresh	public	Refresh token → new access token
GET	/api/v1/auth/me	viewer	Current identity and role
GET	/api/v1/audit	admin	Query the audit trail (filter by user, action, outcome)

Cameras

Method	Path	Role	Description
GET	/api/v1/cameras	viewer	List all cameras
GET	/api/v1/cameras/{id}	viewer	Get one camera
POST	/api/v1/cameras	admin	Add a camera
PUT	/api/v1/cameras/{id}	admin	Update camera
DELETE	/api/v1/cameras/{id}	admin	Remove camera

Events

Method	Path	Role	Description
GET	/api/v1/events	viewer	Query events (camera_id, rule_type, priority, limit, offset)
GET	/api/v1/events/{id}	viewer	Get single event
GET	/api/v1/events/stats	viewer	Aggregate statistics (24h default)

Note: the query/response field is rule_type (intrusion, loitering), not event_type.

Zones

Method	Path	Role	Description
GET	/api/v1/zones?camera_id={id}	viewer	List zones (optional filter)
POST	/api/v1/zones	operator	Create zone
PUT	/api/v1/zones/{id}	operator	Update zone
DELETE	/api/v1/zones/{id}	operator	Remove zone

Note: the polygon field is coordinates, not polygon: {"camera_id":2,"name":"Dock","zone_type":"restricted","coordinates":[[0,0],[640,0],[640,480],[0,480]]}

Cross-Camera Tracking

Method	Path	Role	Description
GET	/api/v1/cross-camera/tracks	operator	Active global tracks
GET	/api/v1/cross-camera/targets	operator	Currently targeted persons
POST	/api/v1/cross-camera/target	admin	Start targeted tracking
DELETE	/api/v1/cross-camera/target/{id}	admin	Stop targeted tracking
GET	/api/v1/cross-camera/path/{id}	operator	Movement path for a person
GET	/api/v1/cross-camera/predict/{id}	operator	Predicted trajectory
GET	/api/v1/cross-camera/graph	operator	Get camera adjacency graph
POST	/api/v1/cross-camera/graph	admin	Set camera adjacency graph
POST	/api/v1/cross-camera/clear-old	admin	Prune tracks older than N hours
GET	/api/v1/clusters	viewer	DBSCAN trajectory clusters

Analytics & Vision

Method	Path	Role	Description
GET	/api/v1/analysis/{camera_id}	viewer	Full analysis: detections, speed, height, face, LPR, pose, anomalies
GET	/api/v1/anomalies	viewer	Recent anomaly events
GET	/api/v1/trackers	viewer	Deep tracker status + active tracks
GET	/api/v1/poses	viewer	Pose estimation statistics
GET	/api/v1/lpr	operator	LPR system status
POST	/api/v1/enhance/analyze	operator	Image enhancement analysis
POST	/api/v1/video/process	operator	Process a video file through the pipeline
GET	/api/v1/faces	admin	Registered known faces
POST	/api/v1/faces/register	admin	Register a new face
DELETE	/api/v1/faces/{id}	admin	Delete a registered face
GET	/api/v1/faces/status	operator	Face recognition health

System & Webcam

Method	Path	Role	Description
GET	/	public	API banner: name, version, and docs link
GET	/api/v1/health	public	Subsystem health, security posture, retention status
GET	/metrics	public	Prometheus text exposition
GET	/api/v1/metrics	viewer	Dashboard JSON metrics (CPU, RAM, per-camera FPS)
GET	/api/v1/stats/learning	viewer	Adaptive learning metrics
POST	/api/v1/webcam/start	operator	Start PC webcam
GET	/api/v1/webcam/status	viewer	Webcam mode status
POST	/api/v1/webcam/stop	operator	Stop webcam

Perception

Method	Path	Role	Description
GET	/api/v1/perception/tracks	viewer	Every tracked entity in the world model, with its accumulated attributes
GET	/api/v1/perception/tracks/{track_id}	viewer	One entity: attributes, trajectory, relationships, observations
GET	/api/v1/perception/tracks/{track_id}/explain	viewer	Evidence chain — measurements and inferences under separate keys
GET	/api/v1/perception/capabilities	viewer	What can run here, measured cost, and why anything is unavailable
GET	/api/v1/perception/changes	viewer	Per-camera change baselines and whether they are mature enough to judge
GET	/api/v1/perception/stats	viewer	Throughput and measured per-stage cost

/explain is the endpoint to reach for before acting on an alert. It never returns a single confident narrative: measured holds only direct observations, inferred and relationships hold conclusions drawn from them, and each carries grounded (is there a measurement under this?) and actionable (grounded and above the confidence floor). A conclusion that rests only on other conclusions is reported as not actionable however confident it looks.

/capabilities is deliberately blunt about what this host cannot do. On a machine with no CUDA and no OCR engine it reports 12 of 18 capabilities available, each unavailable one naming the reason and the remedy — for example ocr explains that tesseract is missing and that text regions are still being detected without it.

Rules, Coverage & Event Lifecycle

Method	Path	Role	Description
GET	/api/v1/rules/status	viewer	Per rule: configured, implemented, and whether it can actually fire here — with the specific blocker when it cannot
GET	/api/v1/rules/calibration	viewer	Per-camera ground-plane calibration, and what its absence disables
GET	/api/v1/observations/promotion	viewer	How many perception observations became events, and which kinds are deliberately not promoted
GET	/api/v1/events/lifecycle	viewer	The permitted event state machine, so clients need not hardcode it
PATCH	/api/v1/events/{event_id}/status	operator	Advance an event; records the acting user. Illegal transitions return 400
GET	/api/v1/notifications/status	viewer	Which alert channels can actually deliver right now, plus policy and suppression counters
POST	/api/v1/notifications/test	admin	Send a synthetic alert through every channel and report the real per-transport outcome
GET	/api/v1/evidence/status	viewer	Pre-event ring-buffer occupancy per camera and clip counters
GET	/api/v1/events/{event_id}/clip	viewer	Download the pre-event video clip; 404 with a reason if none, 410 once retention has removed it

Alerts are delivered, not just recorded

MQTTPublisher.publish_event() was fully written and mqtt.enabled was true in config.yaml, but nothing in the codebase ever called it. Every event Argus produced was stored in SQLite and sent nowhere, and no endpoint revealed that. EventStore.create_event — the one choke point every event passes through — now dispatches through a notification service with MQTT and webhook transports, an alert policy (priority floor, allow/deny, midnight-wrapping quiet hours, per-camera rate limit) and counters for everything it drops.

Channel availability is probed live, never inferred from the config flag: with mqtt.enabled: true and no broker running, notifications/status reports the channel as unavailable and gives the reason. A delivery that was never attempted is never reported as sent, and a suppressed alert is counted rather than swallowed. Delivery is best-effort and cannot break event recording — a transport that raises is logged and reported, and the event is still persisted.

Pre-event video evidence

A snapshot shows the instant a rule fired, not the approach. Argus keeps a per-camera ring buffer of recent frames and exports an mp4 when a high-value rule fires (evidence_clips.clip_rules); the path is attached to the event metadata and served from /api/v1/events/{event_id}/clip.

Frames are buffered JPEG-encoded rather than raw, measured on 480p:

	per frame	10 s @ 10 fps, one camera
raw BGR	0.88 MB	88 MB
JPEG q=80	0.005–0.20 MB	0.5–20 MB

Raw buffering costs ~352 MB across four cameras — fatal beside the detection model. Encoding costs ~2 ms/frame against a ~108 ms/frame YOLO budget. The buffer is bounded in bytes as well as frames, because frame size varies ~40× with scene content, so a frame count alone is not a memory guarantee. Clips expire under retention.clips_days with a clips_max_mb ceiling.

A rule declared enabled: true in config.yaml used to mean nothing on its own — speed_violation, fall_detection and abandoned_object were all advertised as enabled while no code evaluated them. They are implemented now, and rules/status exists so the difference between configured and working can never again be invisible.

Two of them refuse to fire rather than guess:

• speed_violation needs per-camera camera_calibration. Multiplying pixel displacement by a global 0.05 m/px guess yields a number that looks like a measurement and is not one. Uncalibrated cameras report the blocker instead.
• fall_detection needs real pose keypoints. The bounding-box aspect-ratio fallback cannot distinguish a fall from crouching or lying down, and a high-priority medical alert must not rest on that.

Memory & Search

Method	Path	Role	Description
GET	/api/v1/memory/recall	viewer	"What happened near the loading bay yesterday?" — free text over observations and their evidence, filterable by camera_id, kind, when, min_confidence
GET	/api/v1/memory/summary	viewer	Plain-language digest of a period — the shift-handover answer
GET	/api/v1/memory/appearances/{camera_id}/{track_id}/similar	viewer	"Where else has this person been?" — ranked by appearance, annotated with travel-time plausibility
GET	/api/v1/memory/stats	viewer	What is stored, which vector backend is live, and its measured limits

when accepts today, yesterday, last_hour, last_week, 24h.

Appearance matches are candidates for review, never identifications. The descriptor compares clothing colour layout in three bands, so two people dressed alike match strongly. Every result carries is_identification: false and the caveat travels in the payload rather than living only in these docs. Matches are also checked for physical plausibility — two cameras seeing matching clothes at the same moment is evidence of two people, and that is reported rather than hidden.

Vector search uses exact brute-force cosine in SQLite (measured: 5 ms at 1k vectors, 37 ms at 10k, 207 ms at 50k). Qdrant is used automatically if a server actually answers — never because config.yaml says enabled: true. Past ~25 000 vectors /memory/stats warns you to run it.

Streaming

Endpoint	Type	Role	Description
/api/ws/stream/{camera_id}?token=<jwt>	WebSocket	viewer	Binary JPEG + JSON detections
/api/stream/{camera_id}	HTTP	viewer	MJPEG stream
/api/mjpeg/stream/{camera_id}	HTTP	viewer	MJPEG fallback stream
/api/snapshots/{camera_id}/{filename}	HTTP	viewer	Saved event snapshots

Browsers cannot set headers on a WebSocket handshake, so the stream endpoint takes the token as a query parameter. The server validates it before accepting the connection.

---

🚢 Deployment

Argus runs anywhere that can run a container. Full guide: docs/DEPLOYMENT.md.

cp .env.example .env
echo "ARGUS_JWT_SECRET=$(openssl rand -base64 48)" >> .env
echo "ARGUS_ADMIN_PASSWORD=choose-a-strong-one"    >> .env
docker compose -f docker-compose.prod.yml up -d

Target	Config	Hosts
Docker / VPS / on-prem	docker-compose.prod.yml	Everything
Render	render.yaml	Everything
Fly.io	fly.toml	Everything
Railway	railway.json	Everything
GHCR image	.github/workflows/deploy.yml	Everything
Vercel	vercel.json	Dashboard only

The container reads the platform's $PORT, creates the schema on first boot, sets the admin password from ARGUS_ADMIN_PASSWORD without ever baking a default into the image, and refuses to start without ARGUS_JWT_SECRET rather than signing tokens with an ephemeral key that logs everyone out on restart.

Two things worth knowing before choosing a host.

Argus needs a disk. All mutable state — the SQLite database, snapshots, evidence clips — lives under ARGUS_DATA_DIR. On a container platform that must be a mounted volume. Mounting one at any other path persists nothing while appearing to work until the first restart.

Vercel cannot host the backend. Not a configuration problem: the dependency set is ~955 MB against a 500 MB function limit, serverless functions cannot hold WebSocket connections open for video, there is no persistent process for the retention thread, and the filesystem is ephemeral. vercel.json therefore deploys the dashboard only; point it at an API hosted elsewhere by setting VITE_API_ORIGIN at build time. Serving the UI from the API container is simpler and has no CORS surface.

---

📈 Observability

curl http://localhost:8000/metrics

Prometheus text exposition — no client library dependency. Exposed metrics:

Metric	Type	Labels
argus_uptime_seconds	gauge	—
argus_process_cpu_percent	gauge	—
argus_process_memory_bytes	gauge	—
argus_camera_fps	gauge	camera_id, name
argus_camera_up	gauge	camera_id, name
argus_camera_queue_depth	gauge	camera_id, name
argus_cameras_total	gauge	status
argus_inference_latency_ms	gauge	—
argus_model_loaded	gauge	—
argus_detections_current	gauge	camera_id
argus_active_tracks	gauge	—
argus_events_24h_total	gauge	rule
argus_auth_enabled	gauge	—
argus_ephemeral_jwt_secret	gauge	—

/metrics is unauthenticated by design so a scraper needs no credentials — it carries operational counters only, no frames, identities, or event contents. Restrict it at the network layer if your threat model requires it.

Structured logging: set ARGUS_LOG_FORMAT=json to emit one JSON object per log line, with any extra={...} fields merged in — so logs can be filtered by camera_id instead of grepped.

{"timestamp": "2026-08-17T16:44:05", "level": "INFO", "service": "argus.ingestion", "message": "camera online", "camera_id": 2, "fps": 14.8}

These metrics are not decoration. Within a minute of /metrics going live it exposed two real bugs — 74 active tracks for a 12-person scene, and 377 loitering events from a single camera — that code review had missed entirely.

---

🧪 Testing

The suites that gate correctness

pytest -q     # collects maintained test_*.py suites under tests/

Check the latest GitHub Actions run for current pass status; suite counts and results change as tests evolve.

Every push and pull request runs these on Python 3.11 and 3.13 via .github/workflows/ci.yml, which additionally boots the real server to assert /health responds, an unauthenticated request is refused with 401, and /metrics emits argus_ lines — plus a secret scan, a gitignore-hygiene check, and a frontend build. See CONTRIBUTING.md.

Suite group	Files	Coverage
Maintained pytest suites	tests/test_*.py	Pipeline regression, API authorization, security hardening, CityOS, and sensor behavior. pytest.ini defines collection.

The regression suite contains targeted cases for previously observed failures. The latest workflow run is the source of truth for whether the current tree passes.

test_api_security.py includes a static sweep that walks the live route table and asserts every /api route outside the public allowlist carries an auth dependency — so a newly added endpoint cannot silently ship unauthenticated.

Swarm A/B benchmark

python tests/swarm_benchmark.py --frames 40 --json docs/swarm_benchmark_results.json

Runs each pipeline variant in a separate process (module-level singletons would otherwise leak state between runs and bias the result). Options: --clip, --frames, --json, --camera-id.

Manual / diagnostic scripts

These are exploratory tools, not assertions — they predate the pytest suites and several require infrastructure that is not part of the default stack:

python backend/scripts/webcam_tester.py --camera 0   # needs a webcam
python tests/infrastructure_healthcheck.py           # needs Kafka/ES/Qdrant
python tests/stream_simulator.py --count 4           # needs ffmpeg
python tests/buffer_monitor.py                       # runs until interrupted

---

❓ Troubleshooting

Symptom	Likely Cause	Fix
Camera "Offline"	Invalid RTSP URL or network issue	Verify URL; check docker-compose logs backend
No events generated	Zones not defined, or confidence too high	Define zones; lower confidence_threshold in config.yaml
WebSocket connection failed	Backend not running / wrong port	Ensure uvicorn on :8000; check Vite proxy in vite.config.js
High CPU usage	Heavy YOLO model + no frame skipping	Use yolov8n.pt; enable evolutionary engine's frame skipping
MQTT not publishing	Broker offline / wrong address	mosquitto_sub -h localhost -t "argus/#" -v to verify
401 on every API call	Auth is enabled and no token was sent	Log in first; the dashboard does this for you. For curl, see Authentication
403 on a WebSocket	Token missing from the handshake	Use ?token=<jwt> — browsers cannot set headers on a WS upgrade
Tokens stop working after restart	ARGUS_JWT_SECRET unset, so an ephemeral key was generated	Set ARGUS_JWT_SECRET to a fixed value ≥32 chars
429 with "Try again in N seconds"	5 failed logins locked the account	Wait out the lockout, or tune ARGUS_LOGIN_LOCKOUT_SECONDS
Login fails for a known-good user	Password not hashed by Django, or user inactive	Create/reset the user through Django admin
Address already in use on :8000	A previous uvicorn is still holding the port	ss -lntp | grep :8000 then kill -9 <pid>
Detections appear but track_id is always 0	Tracker silently failed and the exception was swallowed	Check logs for Error updating tracker; run pytest tests/test_regression.py -k Track
Event feed floods with duplicates	Old build without sliding-window dedup	Update; dedup now keys on track ID and slides while a condition persists
Zone POST returns 422	Wrong field name	The polygon field is coordinates, not polygon
Frontend shows nothing but the login box	Backend unreachable through the Vite proxy	Confirm uvicorn on :8000; check vite.config.js proxy
npm run dev/vite build dies with "Killed" or "The service was stopped"	Out of memory — esbuild and a torch-loaded backend on the same small machine	Build with the backend stopped, or give the machine more RAM (~2 GB is not enough for both)

---

📁 Project Structure

argus/
├── README.md, FOLDER_STRUCTURE.md, PRODUCTION_ROADMAP.md, TODO.md,
│   INTEGRATION_TODO.md, CONTRIBUTING.md, CHANGELOG.md, LICENSE
├── .github/workflows/ci.yml              # Lint, secret scan, tests (3.11/3.13), frontend build
├── pytest.ini                            # Test collection + markers
├── .dockerignore                         # Keeps .git/node_modules/data out of build context
├── requirements.txt                      # Core deps (incl. PyJWT)
├── requirements-optional.txt             # Heavy/optional extras (django, kafka, qdrant…)
├── .env.example                          # Every ARGUS_* variable, documented
├── config/config.yaml                    # Agents, rules, retention; supports ${VAR}
├── Dockerfile                            # Production image (API + built dashboard)
├── docker/, docker-compose.yml           # Development container builds
├── docker-compose.prod.yml               # Production stack (single image + volume)
├── Makefile                              # make start / make stop shortcuts
├── render.yaml, fly.toml, railway.json   # One-click platform blueprints
├── vercel.json                           # Static dashboard only - see docs/DEPLOYMENT.md
├── infrastructure/, mediamtx/, mosquitto/
├── data/                                 # argus.db, snapshots, known_faces, demo_clip.mp4
│
├── backend/
│   ├── api/
│   │   ├── main.py                       # FastAPI app, all routes, RBAC, audit middleware
│   │   ├── auth.py                       # JWT, roles, Django password verification, lockout
│   │   ├── observability.py              # Prometheus exposition + JSON log formatter
│   │   ├── models.py                     # Pydantic schemas
│   │   ├── stream_routes.py              # Snapshot & MJPEG (auth-gated)
│   │   └── stream_ws.py                  # WebSocket streaming (auth before accept)
│   ├── config/config.py                  # Config parser, ${VAR} interpolation, secret redaction
│   ├── database/db.py                    # SQLite schema + CRUD
│   ├── django_admin/                     # Django admin over the same DB (auth_user lives here)
│   ├── models/yolov8n.pt                 # Detection weights
│   ├── services/
│   │   ├── core_engine/                  # inference_engine, deep_tracker, yolo_detection_agent,
│   │   │                                 #   consortium_broker, processing_coordinator,
│   │   │                                 #   evolutionary_engine, logic_mutator
│   │   ├── vision/                       # face_recognition, lpr, pose, image_enhancement
│   │   ├── analytics/                    # person_reid, cross_camera_tracker, anomaly_detector
│   │   └── management/                   # rules_engine, zone_manager, event_store, retention,
│   │                                     #   audit_log, mqtt_publisher, stream_ingestion
│   └── scripts/                          # webcam_tester, init_db, run_admin, create_test_events
│
├── frontend/
│   ├── src/App.jsx                       # Shell + auth gate (login vs dashboard)
│   ├── src/theme.js                      # Control-room design system; severity colours
│   ├── src/pages/CommandCenter.jsx       # Video wall, alert feed, delivery + evidence state
│   ├── src/pages/Login.jsx               # Login screen
│   ├── src/pages/                        # CameraManagement, EventFeed, AnalyticsDashboard,
│   │                                     #   AdaptiveLearningDashboard, MemoryExplorer
│   ├── src/components/CameraTile.jsx     # Live tile: WS frames + letterbox-correct overlays
│   ├── src/components/ClipPlayer.jsx     # Authenticated pre-event clip playback
│   ├── src/components/EvidenceImage.jsx  # Authenticated snapshot fetch
│   ├── src/components/ui.jsx             # Panels, metrics, status dots
│   └── src/services/api.js               # Axios client, token store, transparent refresh
│
├── tests/
│   ├── test_regression.py                # 23 pipeline-correctness tests
│   ├── test_api_security.py              # 21 auth/RBAC/secret tests
│   ├── swarm_benchmark.py                # Swarm vs linear A/B harness
│   └── (diagnostic scripts: buffer_monitor, stream_simulator, …)
│
└── docs/                                 # Architecture, testing guide, research notes,
                                          #   swarm_benchmark_results.json

---

📄 License

MIT License — see LICENSE.
