feat(seo): Open Graph card, trailing-slash links, search-language titles

[zz-plant]

Summary

Follow-up to #30. A crawl of the published site found three problems:

• no page had an og:image;
• seven internal links 301-redirected;
• three page titles did not use the words people search for.

This PR fixes all three. It also makes CI run lint and tests, so the redirect check gates merges. For those to run on Linux, the lockfile had to record the Linux builds of three native packages.

Changes

Open Graph card (social-card.mjs, build.mjs)

• The build renders dist/social-card.png, 1200×630, about 49 KB. The PNG is a build output, not a committed file; after deploy it is at https://refract-org.github.io/refract-docs/social-card.png.
• Layout. On the --bg-deep background (#07090f):
  • the site's triangle icon in --accent teal, then "Refract" in bold white;
  • the positioning line in --text, word-wrapped to three lines;
  • a --border-strong rule, then refract-org.github.io/refract-docs in --text-muted.
• The card is drawn from SITE_NAME and SITE_DESCRIPTION, so it changes when the positioning line changes. A description too long for the card fails the build instead of being clipped.
• Every page's head now has:

  <meta property="og:image" content="https://refract-org.github.io/refract-docs/social-card.png">
  <meta property="og:image:width" content="1200">
  <meta property="og:image:height" content="630">
  <meta property="og:image:alt" content="Refract. A deterministic observation engine for revision histories. It reads a page&#39;s edits and emits a typed event for each change.">
  <meta name="twitter:card" content="summary_large_image">

• Font. The site's stack starts with system-ui, which resolves to the reader's OS face (SF Pro, Segoe UI); neither may be redistributed in an image. The card uses Roboto, the stack's OFL-licensed face. It is loaded from @expo-google-fonts/roboto, and system fonts are never loaded, so every machine renders the same PNG.
• Rendering. @resvg/resvg-js turns an SVG into the PNG in about 70 ms per build. Both new packages are devDependencies.
• No per-page titles on the card. That would mean 53 PNGs (about 2.6 MB) and about 3 s more per build. The build runs three times per npm test. Platforms also print og:title beside the image.

Trailing-slash links (build.mjs rewriteLink)

GitHub Pages serves dist/<slug>/index.html at <slug>/ and 301-redirects <slug>. The resolver added the slash only to links ending in .md, so these seven links redirected:

Page	Link
mcp	[CLI reference](cli)
schema, sdk	(./cli)
downstream	(schema#version-compatibility)
index	(python-sdk), (visualizer)
visualizer	(tutorials/refract-ui)

• rewriteLink now resolves every relative link to a page (cli, ./cli, cli/, cli.md, ../index.md) to the page's trailing-slash URL.
• A path whose last segment has a file extension (.svg, .png, .ipynb) is an asset and keeps its form.
• Links with any URL scheme, such as mailto:, are left as written. Before, only http(s) links were.
• The markdown sources keep their slash-less links, so the built-site test still exercises the resolver on them.

Retitles

Each <title> comes from the page's H1, so these H1s changed:

Page	Before	After
/mcp/	MCP — Model Context Protocol — Refract	Wikipedia & MediaWiki revision-history MCP server — Refract
/tutorials/wikipedia-history/	Tutorial: Track changes on a Wikipedia page — Refract	Track changes to a Wikipedia article over time — Refract
/compare/	Refract vs. Wikipedia's page history — Refract	Wikipedia history tools compared — Refract

• MCP. The server's analyze and export tools take an api parameter, the base URL of any MediaWiki API. That makes "Wikipedia & MediaWiki" accurate. The description is unchanged: it still comes from the first paragraph.
• Tutorial. The other 18 tutorials keep their "Tutorial:" prefix. This one drops it so the search words come first. The sidebar still lists it under Tutorials.
• Old H1 anchors. These change, but no page links to them.
• Compare. The intro now names the tools the page compares and the question each answers. Its first sentence is the new meta description: "This page compares tools for reading a Wikipedia article's history: the built-in page history, XTools, WikiBlame, Who Wrote That? and Refract."

Corrections on the compare page

Each claim about another tool was checked against that tool's documentation, and the page links it.

Claim	Was	Now	Source
Page history: find when a sentence first appeared	Manual — search each revision	Not built in. On English Wikipedia the history page's "Find addition/removal" link opens WikiBlame	Help:Page history
Page history: detect edit wars	Manual	Partly. Undos, rollbacks and manual reverts are tagged, and so are the edits they revert	Manual:Reverts
Page history: hash an export	No — screenshots are the only record	Per revision: a permanent link, and an API SHA-1 of the content	API:Revisions
Page history: automated monitoring	No	Watchlist, with optional email when a watched page changes	Help:Watchlist
WhoColor / WikiBlame	One row: "visual diff highlighting"	Two rows. WikiBlame searches revisions (binary or linear) for where a text was inserted or removed. WhoColor colors text by author	WikiBlame manual, WhoColor
WikiWho	Editor-level authorship attribution	Token-level provenance for about 70 Wikipedias: who added, removed or reinserted each token	WikiWho
Wikimedia Enterprise	Commercial licensing	Snapshot, On-demand and Realtime APIs; free access and paid plans. Customers buy a service, not a licence	Enterprise FAQ
XTools, Who Wrote That?	Absent	New rows	XTools, Who Wrote That?

The closing line no longer says the page history lacks hashed exports and monitoring.

CI and lockfile

• ci.yml ran only npm run build. It now runs npm run lint and npm test first.
• Lockfile. The first CI run failed: Cannot find module '@biomejs/cli-linux-x64/biome'. On main, package-lock.json lists only the darwin-arm64 builds of @biomejs/biome, rolldown (Vitest's bundler) and lightningcss. So npm ci on Linux installs no Biome or Rolldown binary, and lint and tests cannot run there.
• Fix. Those entries were re-resolved with npm install --package-lock-only, and the lockfile now lists every platform's build.
  • Biome 2.5.15 and Rolldown 1.0.2 keep their versions.
  • lightningcss moves from 1.32.0 to 1.33.0 (released 2026-07-20), within Vite's ^1.32.0 range.
  • No other package version changes.

Tests

28 new tests; 103 in total, up from 75.

• Redirects (tests/links.test.ts). Fails if any internal link in the built site points at a directory without the trailing slash. Absolute links to the published site, such as the canonical URL, count as internal.
• rewriteLink: unit tests for page, asset and external links. build.mjs now builds only when run as a script, so tests can import it.
• Head tags (tests/seo.test.ts): og:image, its width, height and alt, and twitter:card on every page.
• Card: the published PNG is 1200×630 and over 20 KB, which a blank rectangle is not; lines wrap within the card; SVG text is escaped; a description too long for the card throws.
• Escaping: the <title> element is now escaped (the MCP title contains &); every & in the head outside scripts starts a character reference.
• Mutation checks: each of these makes a test fail:
  • the old resolver (9 failures);
  • an unescaped <title>;
  • twitter:card set to summary;
  • a relative og:image;
  • no card written.

Verification

• npm run lint: no errors. The 3 warnings are the existing noDescendingSpecificity ones in assets/style.css.
• npm test: 4 files, 103 tests pass.
• CI on this branch runs npm ci, lint, tests and build on Ubuntu, and all pass.
• npm run build: 53 pages, plus dist/social-card.png (PNG, 1200×630, 8-bit RGBA, 49,509 bytes). Rebuilding produces the same bytes.
• A separate scan of the built site checked 3,279 internal href, src and content URLs. None redirects or is missing.
• On the live site, /refract-docs/cli returns 301 to /refract-docs/cli/.

Not in this PR

• Unused images. The 18 placeholder refract-docs-*.png scene images in docs/assets/ are still there, along with source.svg, scripts/generate-scenes.ts and check-assets.ts. No page references them, and removing them is a separate decision.
• MCP intro. The first paragraph, which is also the description, does not mention Wikipedia or MediaWiki. The new title does.
• AI-evaluation section on the compare page. It says Refract "has no direct competitor". That is not a comparison of history tools, and this PR does not check it.
